技术参数：
|
型号 |
MI170 |
|||
|
测量范围 |
EC |
0.00 to 29.99 μS/cm; 30.0 to 299.9 μS/cm; 300 to 2999 μS/cm; 3.00 to 29.99 mS/cm;30.0 to 200.0 mS/cm; up to 500.0 mS/cm |
||
|
TDS |
0.00 to 14.99 mg/L (ppm); 15.0 to 149.9 mg/L (ppm); 150 to 1499 mg/L (ppm);1.5 to 14.99 g/L (ppt); 15.0 to 100.0 g/L (ppt); up to 400.0 g/L |
|||
|
NACL |
0.0 to 400.0% |
|||
|
温度 |
-20.0 to 120.0°C / -4.0 to 248.0°F |
|||
|
分辨率 |
EC |
0.01 μS/cm; 0.1 μS/cm; 1.0 μS/cm; 0.01 mS/cm; 0.1 mS/cm |
||
|
TDS |
0.01 mg/L; 0.1 mg/L; 1.0 mg/L; 0.01 g/L; 0.1 g/L |
|||
|
NACL |
0.1% |
|||
|
温度 |
0.1°C / 0.1°F |
|||
|
精度 |
EC |
±1% of reading ±(0.05 μS/cm or 1 位) |
||
|
TDS |
±1% of reading ±(0.05 μS/cm or 1 位) |
|||
|
NACL |
±1% of reading |
|||
|
温度 |
±0.4°C / ±0.8°F |
|||
|
校准 |
EC |
1 点斜率，6个记忆校准点 (84.0 μS/cm, 1413 μS/cm, 5.00 mS/cm, 12.88 mS/cm, 80.0 mS/cm, 111.8 mS/cm) |
||
|
NACL |
1点， MA9066 |
|||
|
温度 |
2 点, 0 to 50°C / 32 to 12 °F |
|||
|
温度校准 |
自动补偿，-20.0 to 120.0°C / -4.0 to 248.0°F |
|||
|
温度系数 |
0.00 to 6.00%/°C |
|||
|
电极 |
MA814D/1 4环，内置温度传感器 |
|||
|
TDS系数 |
0.40 to 0.80 |
|||
|
LOG查询 |
每个范围50组历史数据 |
|||
|
GLP功能 |
最后的EC, NaCl 校准日期 |
|||
|
数据接口 |
RS232 / USB |
|||
|
适用环境 |
0 to 50°C / 32 to 122°F; max RH 95% |
|||
|
电池类型 |
12 VDC电源适配器 |
|||
|
尺寸/重量 |
230 x 160 x 95 mm/0.9K g |
|||
