| Model No |
TN253L |
| Description |
IRT//IRT for Food |
| Status of Sample/Production |
38657 |
| Measurement Range |
-55~300°C -67~572°F |
| Operating Range |
0~50°C 32~122°F |
| Accuracy, Tobj=15-35°C Tamb=25°C |
+/-1.0°C |
| |
|
| Accuracy #AC( above -33°C) |
+/-2%,2°C #Acm (-33~300°C) |
| |
|
| Resolution at -9.9~199.9°C/°F #RE |
0.1°C/0.1°F |
| Repeatibility 25°C#RP |
0.15°C |
| Repeatibility 80°C |
0.75°C |
| Standard COC Point |
0,100°C |
| Response Time (90%) #RTI |
1sec |
| D:S |
6:1 |
| Emissivity |
0.05~1 Step.01 |
| update Frequency(about) |
1.4Hz |
| Dimension [inch] |
tbd ivan |
| Wave Length |
5-14um//8-14um |
| Weight (with battery) [g/oz] |
TBD |
| Thermocouple Probe: |
NA |
| Measurement Range |
|
| (for TN3 TN4: Warning: the actual |
NA |
| range depends on the probe spec) |
|
| Accuracy of Thermocouple #ACpb |
NA |
| Probe Response Time (90%, in still water) |
NA |
| Mode |
Max,Min,Lock |
| Power Supply |
AAAx2 |
| |
|
| Special Features |
|
| |
|
| |
|
| Options: |
|
| ColorBox Dim. #n |
|
| G.W.(ColorBox)#n |
|
| Blister Dimension |
|
| G.W. (Blister) |
|
| metalBox Dimension |
|
| G.W. (metalBox) |
