测量范围
|
-50℃ -1300℃; -50℉ -1999℉ |
|
感应器
|
K Type thermocouple |
|
输入
|
Single(1300), Dual (1302,1303) |
|
分辨率
|
-50℃ + 199.9℃...0.1℃ -50℉ + 199.9℉...0.1℉ (Others-1℃/1℉) |
|
准确度
|
-50℃to 199.9℃...0.3% rdg + 1℃ -50℉to 199.9℉...0.3% rdg + 2℉ -50℃to 1000℃... 0.5% rdg + 1℃ -50℉to 1999℉. ..0.5% rdg + 2℉ 1000℃ to 1300℃..0.75% rdg + 1℃ (apply to main |
|
功能
|
H Data Hold & Display ℃/℉ 选择 0.1°/1° 分辨率选择 T1 & T2 dual points display T1 - T2 differential measurement 3-1/2 digit LCD Overange: 1------ 低电池指示: BT |
|
Temperature Coefficient
|
Less than 0.1 time the applicable accuracy specification per ℃ (℉) |
|
输入保护
|
热电隅最大输入电压:60V DC or 24 Vrms AC 取样率:每秒 2.5次. |
|
操作温度
|
0℃ - 50℃ (32℉-122℉), 0-90% R.H. (0-35℃) |
|
电源
|
one 9V battery |
|
尺寸
|
135mm(L)x72mm(W)x31mm(H) |
|
重量
|
57g |
|
附件
|
电池,使用说明书 |
|
* OPTIonAL TEMPERATURE PROBES
|
Model Range(Type K(CA) THERMOCOUPLE) TP-K01 Bead -50℃ to 200℃/-58℉ to 392℉ General Purpose TP-K02 Immersion -50℃ to 1000℃/-58℉ to 1832℉ Liquid or gels. TP-K03 Surface -50℃to 750℃/-58℉ to 1382℉ |
